Strand7 Snippets |
|
|
Strand7 Snippets are very short articles about very useful features in Strand7. |
|
#8: Defining and Changing Property Numbers Things to know about the creation and reordering of property numbers. |
|
|
#7 SUMMARY/Property Edit Mode List all properties, and edit property data, in grid mode. |
|
|
#6 Right-Click Entity Selection Icons Access additional options to specify the sub-type and the part of an entity to select. |
|
|
#5 Open Result File Options The options icon in the available result files dialog opens the options page, which allows you to hide particular result cases from the result file. For example, for linear buckling analysis you can hide negative modes. |
|
|
#4 Plate Thickness The thickness of plate elements can be defined in the plate property data or via a plate element attribute. Thickness assigned as a plate element attribute supersedes the thickness in the plate property data. |
|
|
#3 Clone Function Quickly create a copy of an open model and immediately open it. |
|
|
#2 Entity Selection Icons Things to know about the Entity Selection Icons. |
|
|
#1 Open File Location Quickly open the folder in which the Strand7 model is located. |
|
